Steel Wound Cores
Steel Wound Cores at EMTL
Welcome to East Manufacturing Technologies Ltd, a leader in the field of advanced magnetic materials. We have a wide range of Steel wound cores available. These include GOES cores, Amorphous cores, and Nano Crystalline cores. These cores are specifically designed for modern industries and cover an array of applications.
We focus on innovation and quality to make sure our products are advanced and perform well in different uses. From renewable energy solutions to advanced electronics, our magnetic cores play a crucial role in enhancing efficiency and reliability. Our expertise extends to customising these cores to fit unique project requirements, ensuring optimal functionality and integration.
We are proud of our ability to change with the industry, always looking for new ways to make our products better. Our team of experts works closely with clients to understand their challenges and provide solutions that not only meet but exceed expectations. At East Manufacturing Technologies Ltd, we aim to advance magnetic technology and develop innovative products for various industries. Our goal is to push the limits and drive progress.
GOES Cores
Customisable to specific sizes, these toroids are ideal for current transformers and chokes. They offer a closed flux path, low magnetic leakage, and compact dimensions. Their design minimises humming and ensures efficient operation, making them a preferred choice in sensitive electronic equipment.
The flexibility in size customisation allows for precise adaptation to various project requirements, enhancing the overall efficiency of the devices they are integrated into. These toroids are particularly beneficial in applications where space is at a premium but performance cannot be compromised.
Similar to toroids, these rectangle cores are customisable and used in current transformers and high-voltage transformers. Their rectangular shape provides an alternative flux path configuration, offering versatility in design and application. These cores are helpful in bigger transformer designs as their shape allows for better winding arrangements and thermal management. The ability to customise these cores to specific dimensions ensures that they can be perfectly tailored to meet the needs of a wide range of high-voltage applications.
Manufactured similarly to Rectangle Cores, C-Cores are cut and polished for a perfect finish. They are used in transformers, chokes, and reactors. The C shape allows for easy assembly and disassembly, facilitating maintenance and repair processes.
These cores are highly magnetic and suitable for high-power applications. They have the ability to store a large amount of magnetic energy without significant energy loss. Their design also allows for the addition of air gaps, which can be used to fine-tune inductance and accommodate high DC bias conditions.
E cores are widely used for transformers and chokes. They are efficient and versatile, with a closed flux path and customisable sizes. Their design facilitates easy winding and assembly, making them a practical choice for manufacturing processes.
E cores are commonly used in transformers. They are known for their low magnetic leakage and humming. This helps to improve the efficiency and reliability of the systems they are used in. The ability to customise their size makes them adaptable to a variety of applications, from small electronic devices to larger industrial machinery.
Amorphous and Nano Crystalline Cores
Known for their high Bsat levels and low core loss, these toroids are ideal for current transformers and chokes. Their unique amorphous structure results in superior magnetic properties, making them highly efficient in electromagnetic applications. Toroids are particularly effective in reducing energy wastage and enhancing the performance of electrical systems.
Their design allows for compact and lightweight solutions, making them suitable for space-constrained applications. Additionally, their high saturation levels ensure that they can handle significant power without saturation, a critical factor in maintaining performance in high-current environments.
Suitable for AC/DC reactors and transformers, Amorphous E cores provide high inductance and saturation with excellent temperature stability. Their E-shaped design makes them popular in manufacturing electrical components due to efficient winding and assembly processes.
These cores are particularly valued for their ability to maintain stable inductance over a wide temperature range, ensuring consistent performance under varying operating conditions. These devices are suitable for high-power applications. Efficiency and minimising losses are crucial in such applications. The reason for their suitability is their high saturation flux density. The Amorphous E cores’ robustness and reliability make them indispensable in modern electrical and electronic systems.
These cores are ideal for UPS systems and high-power switching transformers. They have a high saturation flux density and low core losses. These cores have a C shape that helps reduce energy losses in power applications by creating an efficient magnetic circuit.
Their amorphous nature contributes to their ability to operate effectively under high stress and temperature conditions, making them reliable components in critical power systems. These cores are versatile and can be customised to meet design requirements, ensuring optimal performance in power applications.
These toroids are ideal for charging electric vehicles and using sensors. They have high permeability, low power loss, and increased impedance at higher frequencies. Their special structure gives them very good magnetic properties, saving energy and improving electronic performance.
Toroids are very effective in situations where space and weight are important. Their small size does not impact their power handling capability. They can perform well at different frequencies, making them useful in many technological applications, like sensors and electronic circuits.
Suitable for a variety of applications, Nano Crystalline E cores offer high inductance, excellent saturation, and good temperature stability. Their E-shaped design helps distribute magnetic flux efficiently, reducing energy losses and maximising performance. These cores are widely used in power conversion and signal processing. They have high saturation levels and low core losses, which make them more efficient and generate less heat.
Nano Crystalline material is both high-performing and durable, making it a reliable option for industrial and consumer electronics. Their versatility and superior properties make them an integral component in advancing the efficiency and effectiveness of modern electrical systems.
Used in EV charging and renewable energy applications, these cores provide high permeability and low coercive field strength. Their design is optimised for applications requiring high efficiency and minimal energy loss, making them ideal for use in sustainable energy solutions.
The cores can be customised to meet specific needs in renewable energy applications. This includes wind turbines and solar panels. This customisation ensures that the cores perform well.
Custom Solutions and Technical Support
At East Manufacturing, we understand the unique requirements of each application. Our team is dedicated to providing customised solutions, working closely with manufacturers to meet specific parameters and enhance efficiency, reliability, and performance.
Advancing Technology with Nano Crystalline Solutions
East Manufacturing Technologies Ltd is committed to advancing technology with our range of Amorphous and Nano Crystalline cores. These materials represent the cutting edge of innovation, offering unmatched efficiency and performance. Whether you need space-saving designs, increased power, or enhanced reliability, our solutions are engineered to exceed expectations. Contact us to discover how our advanced magnetic materials can revolutionise your applications.
For bespoke component manufacturing solutions and more information on our services, reach out to us at +44 1462 680689 or drop an email at sales@east-trading-ltd.com.
East Manufacturing Technologies Ltd is an ISO 9001 approved, ROHS compliant company. We are dedicated to setting the gold standard in component manufacturing. Partner with us for unparalleled quality and service.
